Modified Polysilazane Coatings
Polysilazane resins modified with epoxy, polyester, silicone and acrylic chemistries — coatings that balance ceramic hardness with flexibility, hydrophobicity and specialised functions. Full data per grade in the TDS, provided on request.
The grades
Grades in this family. Specifications are confirmed in the product TDS.
EK-M01
→
Epoxy-modified silazane coating
Paint and coating protection; room-temperature application, short-term up to 500 °C.
EK-M04
→
High-gloss modified polysilazane coating
High-gloss protective coating: ≥7H hardness, >110° water contact angle, to 200 °C.
EK-M06
→
One-component polyester-modified polysilazane resin
Polyester-modified polysilazane resin addressing toughness and bend resistance.
EK-M08
→
Silicone-modified room-temperature-curing resin
One-component silicone-modified polysilazane, room-temperature grade.
EK-M101
→
Flexible polysilazane for release and hydrophobic coatings
Flexible polysilazane rated below 600 °C in air — a step above the 500 °C liquid resins — for release coatings and hydrophobic surfaces.
EK-M102
→
Fluorine-modified polysilazane, 28–30% fluorine
Fluorine-modified polysilazane from the methyl trifluoropropyl series; 28–30% fluorine, water contact angle 105–110°.
EK-M103
→
Fluorine-modified polysilazane, 55–60% fluorine
Highest-fluorine grade in the range — 55–60% fluorine and a water contact angle of 110–120° for superhydrophobic surfaces.
EK-M12
→
Acrylic-modified hydrophobic anti-graffiti coating
One-component acrylic-modified polysilazane; anti-graffiti coating.
EK-M14
→
Hydrophobic anti-fingerprint silicone-modified resin
Nanotech-functionalized polysilazane resin; anti-fingerprint applications.
EK-M20
→
Acrylic-modified polysilazane resin
Acrylic-modified resin grade; formulation and curing data per TDS.
EK-S07
→
High- and low-temperature heavy-duty anticorrosive fluorosilicone coating
Heavy-duty anti-corrosion resin with low-temperature application; fiber sizing agent.
EK-SiBCN
→
Boron-modified polysilazane for wave-transparent and 1700 °C coatings
Boron-modified polysilazane rated to 1700 °C with wave-transparent properties and high-temperature self-healing; two viscosity grades.
Compare grades
How the grades in this family differ. Exact values are confirmed in each product TDS.
EK-M01
One-component coating
−30 to 300 °C · 500 °C peak
Ambient or 150 °C
Epoxy-modified all-rounder, ≥6H
EK-M04
One-component coating
−30 to 200 °C · 300 °C peak
Ambient or 180 °C
High-gloss visible surfaces, ≥7H
EK-M06
One-component resin
−30 to 300 °C · 380 °C peak
Ambient or 150 °C
Polyester toughness without mixing
EK-M08
One-component resin
−30 to 380 °C · 450 °C peak
Ambient or 140 °C
Self-cleaning hydrophobic, >2000 h salt spray
EK-M101
Solvent-free liquid resin
<600 °C in air
150 °C · 1–4 h
Release coatings; flexible film to 600 °C
EK-M102
Solvent-free liquid resin
Not stated in the TDS
200 °C · 4–12 h
Dual-repellent, 28–30% fluorine
EK-M103
Solvent-free liquid resin
Not stated in the TDS
200 °C · 4–12 h
Superhydrophobic, 55–60% fluorine
EK-M12
One-component coating
−30 to 300 °C · 400 °C peak
Ambient or 150 °C
Anti-graffiti duty
EK-M14
One-component resin
−30 to 430 °C
Ambient or 150 °C
Anti-fingerprint, strongest hydrophobicity
EK-M20
One-component coating
−50 to 300 °C · 400 °C peak
Ambient or 150 °C
Hydrophobic anti-graffiti, salt spray >2000 h
EK-S07
One-component coating
−50 to 300 °C
120–140 °C · <2 h
Fluorosilicone heavy anticorrosive, 3000 h
EK-SiBCN
Liquid resin, two viscosities
Up to 1700 °C in air
200–300 °C · 0.5–1 h
Wave-transparent; extreme temperature
* From each grade’s TDS. Final selection is confirmed during technical review.
Key properties
Typical properties of this family — exact values depend on product grade and are confirmed in the TDS.
Tunable properties
Epoxy, polyester, silicone and acrylic modification routes.
Room-temperature cure
Most grades cure ambient with optional heat acceleration.
Hydrophobicity
Water contact angles from 105° up to 120° on select grades.
Hardness with flexibility
4H–7H films that tolerate bending.
Corrosion resistance
Salt-spray ratings from 500 to over 2000 hours.
Special functions
Anti-graffiti, anti-fingerprint, self-cleaning, high gloss.
Applications
Industrial challenges where this material family is typically evaluated.
Anti-corrosion Coatings
→
Protect metal and concrete against moisture, salt and chemical exposure.
Anti-graffiti / Easy-to-clean
→
Low surface energy for easy cleaning of glass, stone and metal.
Automotive Coatings
→
Industrial automotive applications and component protection.
Industrial Metal Protection
→
Corrosion, chemical and thermal protection for metal parts.
Stone / Glass / Ceramic Protection
→
Invisible protection for mineral and glass surfaces.
Documents
Request the documents you need, or start a guided evaluation — everything is provided per product grade.
FAQ
Common questions about this material family.
How do the grades in this family differ?
The grades differ in temperature range and application profile — exact values are in each product TDS. Send your operating conditions and we will recommend a grade.
Can I test the material before committing to volume?
Yes — sample support is available for qualified B2B projects after a short technical review.
Which substrates are compatible?
Steel, stainless and other metals are typical. Compatibility for a specific substrate is confirmed per grade in the TDS.
How is this different from conventional high-temperature paint?
Silazane-derived coatings convert to a dense ceramic layer, designed for service beyond the range of conventional organic paints. Comparative data is available on request.
What is the minimum order quantity?
MOQ depends on the product and packaging format — to be confirmed with our team for your grade.
Send request
From first enquiry to qualified bulk supply — send your requirements below.
01
Send requirement
Application, substrate and performance target.
02
Get recommendation
Suitable material family and product grade.
03
Receive TDS/SDS, catalog & sample
Documentation and sample for evaluation.
04
Test material
Validate on your substrate and process.
05
Confirm & bulk supply
Specification agreement and ongoing supply.
About modified polysilazane coatings
Modification with organic chemistries tunes the polysilazane backbone: epoxy grades add adhesion, polyester adds flexibility, silicone adds hydrophobicity and release behaviour, acrylic adds weathering and anti-graffiti performance. Grade choice follows the property that matters most in your system.
Typical evaluation starts with the substrate, operating temperature and application process. Exact temperature limits, film thickness and curing parameters depend on the product grade and are confirmed in the TDS. Sample support is available for qualified B2B projects.
